6063 Extruded Round Anodize Small Diameter Color Anodized Aluminum Pipe
6063 Extruded Round Anodized Aluminum Pipe
This 6063 extruded round aluminum pipe is produced from the 6063 aluminum alloy, a material widely used for extruded profiles that require a smooth surface, clean lines and dependable forming characteristics. The round section and small diameter format make it suitable for applications where a slender, uniform profile is preferred.
6063 is a heat-treatable aluminum alloy based on magnesium and silicon. It is known for good extrudability, which allows complex cross sections and thin walls to be produced with a consistent finish. The alloy also responds well to anodizing, so the surface can be treated to achieve a durable and decorative appearance.
Surface Finish Options
The pipe can be supplied with an anodized finish, including color anodized options. Anodizing is an electrochemical process that grows a protective oxide layer on the aluminum surface. This layer helps improve resistance to wear and weathering compared with untreated aluminum, while also allowing a range of decorative effects.
Color anodized finishes are chosen when a particular appearance is required alongside the protective benefits of anodizing. Options can include a variety of tones and sheen levels, and the finish can be matched to a project's design intent. Because anodizing is integrated into the metal rather than applied as a coating, the surface keeps a metallic character and does not chip or peel in the way a paint layer can.
Customers with specific appearance requirements are invited to describe the desired finish when making an inquiry so that suitable options can be discussed.
Applications
Round anodized aluminum pipes are commonly used in architecture and interior design, for example in trim, framing, railings, display structures and decorative accents. They also appear in furniture, lighting, sporting goods and general industrial equipment where lightweight metal parts are needed.
The combination of a small diameter round profile with an anodized surface makes these pipes suitable for visible parts that need both a neat appearance and everyday durability in normal service conditions.
Ordering and Customization
We welcome inquiries for this 6063 extruded round anodized aluminum pipe. Please share the dimensions, surface finish and intended application for your project so that the available options can be reviewed. Specific requirements can be addressed on a case-by-case basis.
twist lock aluminum telescopic pole for fruit collection
aluminium main feature:
High weather resistance anti scratch anticorrosion and good weather resistance subtle edges and elegant appearance and easy processing and installation high brightness and hardness. So it is widely used in aluminum window, door, curtain wall, hand railing, normal aluminum profile, decorative and industrial aluminum profile etc.
Detail Description:
|
Item |
Aluminium pipe/pipes Aluminium Tube/Tubes/tubing |
|
Material |
Aluminium |
|
Grade |
1000 series: 1050,1060,1070,1080,1100,1435, etc 2000 series: 2011,2014,2017,2024, etc 3000 series: 3002,3003,3104,3204,3030, etc 5000 series: 5005,5025,5040,5056,5083, etc 6000 series: 6101,6003,6061,6063,6020,6201,6262,6082, etc 7000 series: 7003,7005,7050,7075, etc |
|
standards |
ASTM, ASME,EN, JIS, DIN,GB/T etc |
|
Size |
Outer Diameter:3-250mm |
|
Wall Thickness: 0.3-50mm |
|
|
Length: 10mm -6000mm |
|
|
Surface treatment |
Mill finish Anodized Electrophoresis Powder coating Wooden grain Sand blast |
|
Surface colors |
Nature, silver, bronze, champagne, black, gloden, etc As customized |
|
Temper |
T3-T8 |
|
Moulding/Pattern
|
|
|
Application
|
1. Lighting,solar reflector plate. 2.architectural appearance, interior decoration:ceiling,metope, furniture,cabinets and so on. 3.elevator,nameplate, bags. 4.automotive interior and exterior decoration. 5. Interior decoration: such as photo frame. 6.household appliances, refrigerator, microwave oven, audio equipment. 7. Aerospace aspects. 8, machinery parts processing, mold manufacturing . 9. chemical/insulation pipeline coating. |
Chemical Composition:
|
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Zr |
Impurity |
Al |
|
2014 |
0.5-1.2 |
0.7 |
3.9-5.0 |
0.4-1.2 |
0.2-0.8 |
0.1 |
0.25 |
0.15 |
- |
0.15 |
Rest |
|
2017 |
0.2-0.8 |
0.7 |
3.5-4.5 |
0.4-1.0 |
0.4-0.8 |
0.1 |
0.25 |
0.15 |
- |
0.15 |
Rest |
|
2024 |
0.5 |
0.5 |
3.8-4.9 |
0.3-0.9 |
1.2-1.8 |
0.1 |
0.25 |
0.15 |
- |
0.15 |
Rest |
|
5052 |
0.25 |
0.4 |
0.1 |
0.1 |
2.2-2.8 |
0.15-0.35 |
0.1 |
- |
- |
0.15 |
Rest |
|
5056 |
0.3 |
0.4 |
0.1 |
0.05-0.20 |
4.5-5.6 |
0.05-0.20 |
0.1 |
- |
- |
0.15 |
Rest |
|
5083 |
0.4 |
0.4 |
0.1 |
0.40-1.0 |
4.0-4.9 |
0.05-0.25 |
0.25 |
0.15 |
- |
0.15 |
Rest |
|
5754 |
0.4 |
0.4 |
0.1 |
0.5 |
2.6-3.6 |
0.3 |
0.2 |
0.15 |
- |
0.15 |
Rest |
|
6061 |
0.4-0.8 |
0.70 |
0.15-0.40 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
- |
0.15 |
Rest |
|
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.1 |
- |
0.15 |
Rest |
|
6082 |
0.7-1.3 |
0.5 |
0.1 |
0.4-1.0 |
0.6-1.2 |
0.25 |
0.2 |
0.1 |
- |
0.15 |
Rest |
|
7050 |
0.12 |
0.15 |
2.0-2.6 |
0.1 |
1.9-2.6 |
0.04 |
5.7-6.7 |
0.06 |
0.08-0.15 |
0.15 |
Rest |
|
7075 |
0.4 |
0.5 |
1.2-2.0 |
0.3 |
2.1-2.9 |
0.18-0.28 |
5.1-6.1 |
0.2 |
- |
0.15 |
Rest |
Production Flow
Q. Are you a factory or trading company?
We are a factory company.
Q. How to ensure the quality of your products?
ISO9000, client reqirements, product standards,strict inspection to control raw material,production process and final products
Q. How do you resolve the problem about your products?
Person of aging services: For customer complaints commissioner set up a special complaint handling,complaint issues recorded the first time and find the relevant person in charge of the feedback and resolve. Details check our "Quality corrective action report"
Q. What is the MOQ?
A. Sample order is acceptable, And some samples can be free.
Q. How long do you need the delivery time?
1)Supply within 5-10days (product in our stock list)
2)Custom products need to be calculated according to the quantity
Q.What 's your payment terms?
T/T , L/C at sight , Western Union
Q.How can we get your price ?
We need below information to quote for you:
1. Product Name
2. Standard
3. Material Grade (Chemical Composition)
4. Dimension
5. Quantity
6. The Drawing for Special Parts
